Universal Optical Fiber Supercontinuum Laser Source Single Mode

Product Categories
Wuhan CS Tec Co.,Ltd
Contact Now

Universal Optical Fiber Supercontinuum Laser Source Single Mode

Brand Name : DK

Model Number : DK-YSM

Certification : CE

Place of Origin : China

MOQ : 1

Price : Can be negotiation

Payment Terms : L/C, D/A, D/P, T/T

Product name : non-water cooling single mode fiber laser

Application : cutting metal

Laser model : DK-YSM

Laser brand : DK

Contact Now



Product introduction

DK- YSM SC is a series of non-water cooling lasers. According to the fact that the air cooling fiber laser in the market are mainly 200W~300W, DK makes upgrades of air cooling fiber lasers by applying advanced cooling and heat management technologies, making great progress in power level, optimizing structure and dimensions, and improving the beam quality, which is a big push to the technology of air-cooling fiber laser on the market. It can be widely used in various applications of portable and outdoor conditions. At present, the main product in the DK-YSM SC series is of 500W, and products for scientific research can be customized up to 1000W.



Product features

♦High beam quality

♦Low maintenance cost

♦High adaptation ability

♦Universal modules

♦Small volume



Product specification

 Optical Parameters  DK-YSM 100  DK-YSM 200  DK-YSM 300  DK-YSM 500  DK-YSM 1000
 Operation Mode  CW/Modulation  CW/Modulation  CW/Modulation  CW/Modulation  CW/Modulation
 Polarization State  Random  Random  Random  Random  Random
 Beam   Quality  M2  <1.2  <1.2  <1.2  <1.2  <1.2
 BPP(mm·mrad)  ≤0.4  ≤0.4  ≤0.4  ≤0.4  ≤0.4
 Output Power  100W  200W  300W  500W  1000W
 Output Fiber Diameter  14µm  14µm  14µm(Customizable)  14µm(Customizable)  14µm(Customizable)
 Max. Modulation   Frequency  20kHz  20kHz  20kHz  20kHz  20kHz
 Rise/Fall Time  <20µs  <20µs  <20µs  <20µs  <20µs
 Power Range  10%~100%  10%~100%  10%~100%  10%~100%  10%~100%
 Output Power Instability  ≤2.5%  ≤2.5%  ≤2.5%  ≤2.5%  ≤2.5%
 Center Wavelength  1080±10nm  1080±10nm  1080±10nm  1080±10nm  1080±10nm
 3dB Spectral Width  <4nm  <4nm  <4nm  <4nm  <4nm
 Indicated Light   Wavelength  635nm  635nm  635nm  635nm  635nm
 Indicated Light Power  >0.3mW  >0.3mW  >0.3mW  >0.3mW  >0.3mW
 Electronic Control   Parameters 　 　  DK-YSM 300  DK-YSM 500  DK-YSM 1000
 Operating Voltage  DC44V-47V  DC44V-47V  DC44V-47V  DC44V-47V  DC44V-47V
 Laser Power   Consumption  <1.2kW  <1.2kW  <1.2kW  <2kW  <3kW
 Other Parameters 　  　  DK-YSM 300  DK-YSM 500  DK-YSM 1000
 Output Fiber Length  5m  5m  10m(Customizable)  10m(Customizable)  15m(Customizable)
 Cooling  Air Cooling  Air Cooling  Waterless Cooling  Waterless Cooling  Waterless Cooling
 Dimensions  324mm×240mm×185mm  324mm×240mm×185mm  324mm×240mm×185mm  380mm×310mm×230mm  650mm×450mm×222mm
 Weight  10kg  10kg  10kg  15kg  40kg
 Operating Temperature  5℃~35℃  5℃~35℃  5℃~35℃  5℃~35℃  5℃~35℃
 Storage Temperature  -15℃~60℃  -15℃~60℃  -15℃~60℃  -15℃~60℃  -15℃~60℃
 Relative Humidity  20%-80%  20%-80%  20%-80%  20%-80%  20%-80%



Product Samples

Universal Optical Fiber Supercontinuum Laser Source Single Mode

                                              3D Printing

Universal Optical Fiber Supercontinuum Laser Source Single Mode

                                    Cutting of sheet metal
